Adjustable angle wrench M

Adjustable angle wrench M

1.5 times higher strength than JIS powerful class wrenches (M200 to 375).
LOBSTER original adjustable angle wrench.

・Tightening and loosening nuts and bolts

Use/Application

【 Functions 】

・LOBSTER has been making adjustable wrenches for 80 years.
・They are manufactured under complete quality control based on strict in-house standards.
・Their strength is higher than JIS powerful class wrenches.
・The body and parts undergo proprietary machining on purpose-specific machinery
 in a streamlined production process from forging to finishing that renders uniform precision
 and excellent durability.


Applicable bolt thread diameters and width across flats : Click here

ROHS

Specifications

Adjustable angle wrench M

Model No. (Product) weight size1 size2 size3 Jaw Capacity Bolt, nut maximum dimension Torque strength Retail/User prices
M100 50g 110mm 4.0mm 9.0mm 0~13mm M8 73 open price
M150 120g 160mm 6.0mm 10.0mm 0~20mm M12 184.9 open price
M200 250g 206mm 7.5mm 13.0mm 0~24mm M16 411.9 open price
M250 440g 258mm 9.0mm 15.5mm 0~29mm M18 691.4 open price
M300 700g 304mm 10.0mm 18.0mm 0~34mm M22 1176.8 open price
M375 1350g 385mm 14.0mm 23.0mm 0~44mm M27 2206.5 open price
M450 1900g 465mm 13.5mm 24.0mm 0~53mm M33 3079.1 open price
M600 3400g 615mm 16.5mm 30.0mm 0~67mm M42 3853.8 open price
  • M600

    M600

!IMPORTANT SAFETY INSTRUCTIONS

・Adjust the width across flats with the bolt or nut firmly gripped at the back of the jaw.
・Turn the wrench toward the lower jaw.
・Do not extend wrenches with a pipe, etc.
・Do not use wrenches as a substitute for a hammer.
・Do not apply impact to wrenches by hitting them with a hammer, etc.

!CAUTIONS ON INSCRIBED VALUES

※ Since dimensions, weights, etc. are nominal, there possibly are changes of some numerical values.
※ Specifications may be changed for improvement of the product without prior notices.
※ Listed prices do not include VAT. Please ask our distributor in case of purchases.
