Cordless Rivet nut setter

Cordless Rivet nut setter

The cordless rivet nut setter improves on-site workability.

・The cordless-type N1B1 can be used on any worksite.
・1000 or more rivet nuts can be fastened per full charge.
When fastening LOBSTER rivet nuts with a fully-charged battery pack (BPL1825) mounted. The maximum fastening quantity varies depending on the type of rivet nut.
・The digital stroke adjustment function enables easy stroke length adjustment. Up to 10 data items can be stored.
・A function for preventing thread damage is provided (not available for M3 and M4 rivet nuts).
・Enables easy configuration of foolproof system.

Use/Application

【Product features】






























【TECHNICAL DATA】



Model No.

N1B1

Product weight※1

2.6kg

Stroke

0.1～10ｍｍ（Adjust the stroke length using the button next to the counter.）

Maxlmun output

19.6kN

Overall length × Overall width × Overall height※１

292×76×285mm

Fastening control

Stroke control／A function for preventing thread damage is provided (not available for M3 and M4 rivet nuts).

Applicable rivet nut sizes

M3、M4、M5、M6、M8、M10

Applicable rivet nut materials

Aluminum、Iron、Stainless

Motor specification

18V Brushless

Battery pack（standard）

DC18V/2.5Ah

Large-capacity battery pack (option)

DC18V/5.0Ah

Battery type

Lithium-ion battery









※１ When the battery pack (included in N1B1) is used.





Package item※2

Main body ,battery pack（BPL1825:DC18V/2.5Ah）, charger、power cord for , nose piece (M3,M4,M5,M6,M8,M10) , screw mandrel(M3,M4,M5,M6,M8,M10) , lock nut , spanner ×2 , Hexagon key wrench(4mm) , dedicated blow case

Product weight

5.5kg

Case size

450×370×120mm

JAN Code

4963202012195

Retail/User prices

open price













 ※2 The nosepiece (M6), screw mandrel (M6), and lock nut are mounted to the body before shipment.



【Instruction Manual 】


Download ↓
　Instruction Manual (N1B1 / English)　/　Easy Guide (N1B1 / English)　/　Safety Guide (N1B1 / English)






Product features
Product features
Product features

Specifications

Cordless Rivet nut setter

Model No. (Product) weight size1 size2 size3 size4 size5 size6 size7 Use range Traction power Retail/User prices Remark
N1B1 2.6kg 292mm 285mm 68mm 76mm 90mm 106.5mm 127.5mm M3,M4,M5,M6,M8,M10 19.6 open price Applicable rivet nut materials: Aluminum、Iron、Stainless

!IMPORTANT SAFETY INSTRUCTIONS

Before using this product, be sure to read the Instruction Manual carefully together with the “Easy Guide” and “Safety Guide” included in the product to ensure proper use.

!CAUTIONS ON INSCRIBED VALUES

※ Since dimensions, weights, etc. are nominal, there possibly are changes of some numerical values.
※ Specifications may be changed for improvement of the product without prior notices.
※ Listed prices do not include VAT. Please ask our distributor in case of purchases.
